Measure every machine first.
TANDEM-AXLE OFF-ROAD TOY HAULER
01 / EXTERIORBASE MODEL REFERENCE
TANDEM-AXLE OFF-ROAD TOY HAULER
More garage.
More room to reset.
A 28.2 ft tandem-axle toy hauler with a 22 ft interior, queen bed, four bunks, full fiberglass bath and garage-ready flooring for six published sleepers.
BEST STARTING POINT FORLarger toys and longer crews
The longer, wider body creates more cargo and living flexibility than TH19 while retaining six published sleeping places.
SLEEPINGUp to 6
BATHROOMFull fiberglass bath
INTERIOR22 ft
COOKINGInside + outside
6Published sleeps
28.2 ftOverall length
6,847 lbDry weight
10,000 lbGVWR
600 WRoof solar
64 galFresh water
Published base-model figures. Dry weight excludes cargo, water and travel supplies. Verify the selected unit and purchase build sheet.
01 / WHO IT FITS
Choose it for the way
you actually travel.
Buyers whose machines or camp setup need more garage length and width than TH19.
Published total is six.
Official pages use mixed labels.
Plan food for the crew.
Check vehicle payload.
2 × 100 Ah batteries.
LARGER CARGO
Start with dimensions.
Then plan the beds.
The 22 ft interior and 8 ft exterior width offer more room for machines and the path around them.
- 22 ft interior
- Tandem axle
- Garage-ready flooring
Think about: Verify door opening, interior obstacles, tie-down locations and payload.
THE LARGEST TOY-HAULER FOOTPRINT
Load more.
Leave more aisle.
TH22 adds 3 ft of interior length and extra width over TH19. The larger envelope is its primary advantage for cargo fit, movement and camp conversion.
22 ftInterior length
8 ftExterior width
TandemAxle layout
02 / LIFE INSIDE
Every zone
earns its space.
Queen bed + 4 bunks. Full fiberglass bathroom; confirm wet/full layout on build sheet.
WHAT MATTERS INSIDE
Main sleeping areaA dedicated place to rest
Bunk-bed layoutSleeping space along the sides
Indoor kitchenMeal preparation and cabinet storage
BathroomShower fittings and toilet
TH19 / TH22 shared interior reference. Layout, finishes and fitted equipment vary by selected build.
INTERACTIVE FLOOR PLAN
Garage
22 ft interior
Queen bed + 4 bunks. Review the published plan and confirm dimensions on the selected unit.
22 ft interior22 ft interior
Floor plans and finishes can change by production year and package.
TH SERIES / INDOOR KITCHEN
COMFORT SYSTEMS
Live inside.
Cook outside too.
Indoor and slide-out outdoor propane kitchens. The listed 2.6 cu ft fridge, 16,000 BTU furnace and 13,500 BTU rooftop air conditioner define the everyday comfort envelope.
2.6cu ft fridge / freezer
2Cooking locations
Premium retractableAwning
13,500BTU air conditioning
03 / OFF-GRID SYSTEMS
Know what supports
your stay.
Capacity helps only when matched to weather, group size, appliance load and water habits.
POWER ARCHITECTURE
600 W solar.
200 Ah lithium / 2 × 100 Ah.
The listed system combines roof solar, onboard batteries and a pure sine inverter. Runtime depends on battery chemistry, sunlight and loads.
01 / COLLECT600 WRoof solar
→02 / STORE200 Ah lithium / 2 × 100 AhListed battery bank
→03 / CONVERT2,000 WPure sine inverter
30 AShore power12 V / 110 VElectrical system12 V + USBDevice outlets
BUILT FOR THE ROAD BEYOND
The structure
under the finish.
START WITH THE NUMBERS
Match the vehicle
to the loaded trailer.
Published dry weight6,847 lb
GVWR / maximum loaded rating10,000 lb
Published tongue weight900 lb
04 / COMPLETE SPECIFICATION
Every decision point.
Easy to search.
2027 Base specifications. Compare edition equipment before selecting your build.
01Measurements & weights8 details
External length28.2 ft
Internal length22 ft
External width8ft
External height10.5ft
Internal height6.9ft
Dry weight6,847 lb
Tongue weight900 lb
GVWR10,000 lb
02Sleeping & interior5 details
Sleeps6
Sleeping configuration1× Queen Bed and 4× Bunk Beds
BathroomFull fiberglass wet bath, ventilated, with porcelain toilet
FlooringWood Vinyl Living Area and Aluminum Diamond Plating Flooring in Garage
CabinetryModern 5-Star Timber Finish Veneer
03Kitchen & comfort7 details
Fridge2.6 cu. ft. Fridge/Freezer
StoveOutdoor and Indoor Propane Stove
MicrowaveElectrical Microwave with Four Operating Features
Entertainment24" TV with DVD Function
Air conditioning13,500 BTU air conditioner
Furnace16,000 BTU furnace
InsulationR16 insulation
04Power & water13 details
Total solar output600W (4 × 150W)
Solar panel arrangement4 × 150W
Battery bank total200Ah lithium (2 × 100Ah)
Battery arrangement2 × 100Ah
Battery chemistrylithium
Inverter2,000W pure sine wave
Charging systemSolar + 30A shore power
Shore power30A, NEC-compliant, UL-listed components
Fresh water31.7 gal
Grey water13.2 gal
Black water13.2 gal
Hot waterinstant hot water system
ToiletPorcelain Toilet
05Chassis & exterior13 details
Drawbar / chassisHot Dipped Galvanized Tubular Steel made from RHS 4"x2", 0.15 Wall Thickness, 0.24" Supporting Plates for extra Strength & Durability.
SuspensionControl Arm with Dual Shock Absorbers and Coil Springs
Tires235x75xR15 Off-Road Tires with Two Spare Tires
Wheels15" Alloy Wheels with a Black Powder Coated Finish
Brakes12" Electric Tow Brake with Mechanical Handbrake; Breakaway System Include 2x Safety Chains
Hitch360° articulating off-road hitch (McHitch / DO35 style)
Connector7 Pin Flat Plug
Anderson plug50Amp Anderson Plug
Body materialsAluminum Composite Panels with added Aluminum Diamond Plating
WindowsEurovision Windows with Fly Screen and Privacy Shades
RoofOne Piece Aluminum and Roof Hatch with Shade
AwningPremium Retractable Awning
Recovery hooks2x Rear Facing Recovery Shackles
06Additional equipment2 details
RangehoodSlim Twin Fan with Light Range Hood
LightingLED Reading Lights in Bedroom and Lounge; Wide Angle Side mounted LED Flood Lights
No matching specifications.
Base equipment and specifications from the official model PDF and 2027 Specifications & Pricing Guide.
Open official TH22 PDF ↗TANDEM-AXLE OFF-ROAD TOY HAULER
Choose the layout
that solves your real trip.
Buyers whose machines or camp setup need more garage length and width than TH19. Match the trailer to the tow vehicle and verify the final build before ordering.
